Our centrifugal pumps use advanced design theory to handle abrasive slurries, high-viscosity liquids, and corrosive materials. Compared to competitors, KES Separation pumps offer higher flow rates, superior anti-corrosion and anti-abrasion properties, high-temperature resistance, long life, and easy
Product Features
The 250 family of pumps is designed for pumping drilling fluid or industrial slurries; Our Company adopt advanced design theory, the centrifugal pump can be used to pump abrasive slurries, high viscosity liquid or corrosive slurries. Compared with competitors’ pump, KES Separation Centrifugal pump have many technical advantages including higher flow rate, anti-corrosion, anti-abrasive, bear the high temperature, long life, easy maintenance etc. The centrifugal pump now is widely used in onshore and offshore drilling platforms. We can also offer upstream and downstream product to offer pump system solutions to help clients achieving work target.
When working in solids control system, Centrifugal pump can be used as feeding pump for desander or desilter cyclones; Centrifugal pump can also work with jet mud mixer ; Centrifugal pump can work as transferring pump when required at any points.
KES Separation centrifugal pump normally adopt tungsten carbide mechanical seal, with International top brand bearing. Centrifugal pump spare parts are interchangeable with most of the international Brand pumps which helps clients to source spare parts in lower cost. Centrifugal pump with open impeller design lowers the axial thrust loads, making the pump easier for installation, maintenance and repair.
Technical Parameters of Centrifugal Pump:
Model
Flow (m3/h)
Lift(m)
Power(kw)
Impeller speed
Impeller dia(in)
Weigh(kg)
Dimension(mm)
KSSB3×2-10J
35
35
7.5
1450 (50Hz)
10
445
1585x505x709
KSSB3×2-9J
35
35
7.5
1750 (60Hz)
9
445
1585x505x709
KSSB4×3-11J
45
25
11
1450 (50Hz)
11
464
1585x505x709
KSSB4×3-9.5J
45
25
11
1750 (60Hz)
9.5
464
1585x505x709
KSSB4×3-12J
55
28
15
1450 (50Hz)
12
482
1615x505x709
KSSB4×3-10J
55
28
15
1750 (60Hz)
10
482
1615x505x709
KSSB4×3-13J
65
35
18.5
1450 (50Hz)
13
530
1635x505x729
KSSB4×3-12J
65
35
18.5
1750 (60Hz)
12
530
1635x505x729
KSSB5×4-12J
90
30
22
1450 (50Hz)
12
620
1667x568x729
KSSB5×4-10J
90
30
22
1750 (60Hz)
10
620
1667x568x729
KSSB5x4-13J
120
35
30
1450 (50Hz)
13
642
1741x568x818
KSSB5x4-11J
120
35
30
1750 (60Hz)
11
642
1741x568x818
KSSB6x5-12J
150
30
37
1450 (50Hz)
12
766
1831x558x838
KSSB6x5-9.5J
150
30
37
1750 (60Hz)
9.5
766
1831x558x838
KSSB6x5-13J
200
35
45
1450 (50Hz)
13
786
1861x558x838
KSSB6x5-10J
200
35
45
1750 (60Hz)
10
786
1861x558x838
KSSB8x6-13J
272
35
55
1450 (50Hz)
13
896
1894x650x932
KSSB8x6-11J
272
35
55
1750 (60Hz)
11
896
1894x650x932
KSSB8x6-14J
320
35
75
1450 (50Hz)
14
1230
1968x650x942
KSSB8x6-12J
320
35
75
1750 (60Hz)
12
1230
1968x650x942
Technical Features of Centrifugal Pump
The coaxial thickening design is adopted to reduce the vibration and wear during the operation of the pump and prolong the service life of the pump casing
The pump casing is made of wear-resistant ductile iron alloy, with higher wear resistance during tough conditions
Adopt international top brand bearings with stable operation and long service life
Open impeller design reduces the bearing loading of the shaft effectively; prolong the service life of the bearing
Impeller is made of wear-resistant alloy ductile iron by precision casting, with longer service life;
Anti-loosening impeller lock bolt to eliminate pump damage in case of improper motor hook-up
High quality mechanical seal is adopted to prevent pump leakage and reduce maintenance time
Replaceable sleeve to prevent shaft wear
Base of centrifugal pump adopts integral casting base, steadier during working
All spare parts are interchangeable with International popular brand pumps, the buyer can find parts locally easier and lower the maintenance cost
