S/N

Item

Descriptions

1

Sludge Vacuum Pump

The sludge vacuum pump can be applied to transfer the oily sludge to the pre-mixing tank of sludge system. In some cases, submersible slurry pump can also be used for the same purpose.

2

Pre-mixing tank

The pre-mixing tank is equipped with heating coil to heat the sludge, also water feeding port to dilute the heavy sludge, to make it better flowability and easier to separate

3

Screening Tank

The screening tank is equipped with sealed sludge screening shaker, agitator etc. The big particles will be separated out of the system by shaker screen.

4

Polymer Unit

The polymer unit can be used to prepare PAC and PAM, the selection of polymer should be according to the actual situation by users.

5

Centrifuge Separation Unit

The centrifuge separation unit consist of 2 phase decanter centrifuges to separate the fine solids from the sludge, the slurry discharged from decanter will be feeding to disc stack separator. After the 2 stages separation, clean water, clean oil and dry mud cake can be achieved.

6

Remark

Some customer may prefer to 1set tricanter instead of 1set decanter and 1set of disc stack separator. That will be also good choice; and do select good brand tricanter to ensure the separation performance.
